CHAPTER 2

Overview of SETU VFXTH

SETU VFXTH is a gateway that provides voice services over IP network using SIP protocol. It is an effective and
flexible solution for accessing internet based telephone services and corporate intranet systems across established
LAN.
It is an innovative enterprise gateway that offers excellent functionality and sound quality. It supports different voice
ports viz. FXO, FXS and SIP for providing voice services.
It is a feature packed gateway to fulfill the requirements of SOHO (Small Office-Home Office) users as well as
Medium scale Enterprises.
SETU VFXTH is available in the following configurations:
Sr. No. Configuration
1 SETU VFXTH0016
2 SETU VFXTH0024
3 SETU VFXTH0032
4 SETU VFXTH1600*
5 SETU VFXTH3200
6 SETU VFXTH0808
7 SETU VFXTH1616*
*
SETU VFXTH1600 and SETU VFXTH1616 has been discontinued. However, software support is still provided through Jeeves
for the users who have already installed it.
For a complete list of Hardware and Software features, refer
Matrix SETU VFXTH System Manual

Know Your SETU VFXTH

Voice
Channels
16
24
32
16
32
16
32
FXO Ports FXS Ports
0 16
0 24
0 32
16 0
32 0
8 8
16 16
"Product Specifications"
Physical Port Labels
FXO FXS
0 P01-P16
0 P01-P24
0 P01-P32
P01-P16 0
P01-P32 0
P01-P08 P09-P16
P01-P16 P17-P32
in the Appendix.
4
