LEDs
SETU VFXTH0032 has a Power LED (PWR), a Status LED (STS) and 32 FXS Port LEDS (P01 to
P32). The LEDs indicate the status of the ports, and various events occurring on the ports,
including errors.
LED
Description
PWR
Power LED. Turns on when power is supplied.
STS
System LED. Blinks to indicate health of the system.
P01 to P32
Power LED. Turns on when power is supplied.
SETU VFXTH is easy to install and operate. The built-in web server, JEEVES, allows you to
configure the system parameters and features On-site as well as from a remote location.
1.
Depending on the configuration of your SETU VFXTH, the number of FXS/FXO Port LEDs may vary.
Matrix SETU VFXTH Quick Start
Color
Single color
Dual color
Single color
3
