Powering ON SETU VFXTH
• Connect the power adapter to SETU VFXTH.
• Plug in the power adapter of SETU VFXTH into the power outlet.
• Switch on power supply and wait for the Reset Cycle to complete.
Reset Cycle
The Reset Cycle (Power-ON Self Test) takes about 2 minutes to finish.
LED Indication - Reset Sequence
At Power ON, Power LED will turn ON (Continuous Green). Initialization process will start within
15 to 20 seconds and LED sequence of all other LEDs during initialization process is shown in the
table given below:
System
Color
Status
Application
Red
Load
All Init
Red
Done,
System
goes Live
•
During Off-hook state, FXS Port LED glows Red continuously.
•
If the system is in programming mode, the LED of the port used to enter the programming
mode glows Green continuously. After exiting programming mode, the LED for that port glows
Red (to indicate Off-hook state).
You may now access the web-based programming tool, Jeeves, and configure SETU VFXTH.
Matrix SETU VFXTH Quick Start
STS
P01
P02
OFF
ON
ON
ON
ON
ON
OFF
OFF
OFF
P03
P04
P05
ON
OFF
OFF
ON
ON
ON
OFF
OFF
OFF
P06
....
P32
OFF
OFF
OFF
ON
ON
ON
OFF
OFF
OFF
Time
(ms)
1000
ms
1000
ms
7
