SETU VFXTH provides an embedded web server with a Graphic User Interface (GUI), Jeeves, for

configuration.

To access Jeeves, you will need to connect a computer to SETU VFXTH.

You may connect a standalone computer to SETU VFXTH or grab any computer connected in the

same LAN as SETU VFXTH.

Ethernet

WAN

Computer

SETU VFXTH

Connect a standalone computer to SETU VFXTH, when installing the system for the very first time.

You may connect it to the LAN after you have finished installation and configuration of the system.

To connect a standalone computer,

• Plug one end of the Ethernet cable supplied with the system into the Ethernet Port of SETU

VFXTH. Plug the other end into the LAN port of the computer.

• Make sure the IP Address of the computer and the Ethernet Port of SETU VFXTH do not

conflict, and that both are in the same Subnet.

The default IP Address of the Ethernet Port of SETU VFXTH: 192.168.1.100

The default Subnet Mask of the Ethernet Port of SETU VFXTH: 255.255.255.0

• Change the Subnet of the computer, if necessary.

• Make sure a Web-browser, either Internet Explorer version 7 or later or Mozilla Firefox version

3.5 or later, is installed on the computer.

• Open the browser on the computer.
