4
System Installation
This chapter provides information about how to install the Acme Packet 4600 System
and its associated components, includes cabling information.
Shipped Parts
Each Acme Packet 4600 ships in one box. Inside this box is the Acme Packet 4600
chassis and the accessory kit. The ordered NIU and power supplies are already
installed in the chassis.
Table 4-1
Location
Main Shipping Box
Accessory Kit
Installation Tools and Parts
The following tools and parts are required to install the Acme Packet 4600 into your
equipment rack:
•
#1 Phillips-head screwdriver
•
#2 Phillips-head screwdriver
•
Small flat-head screwdriver
•
Rack and associated mounting hardware
•
Shielded Ethernet CAT5e or CAT6 RJ45 cables
•
11/32" nut driver
Recommended Tools and Parts
Acme Packet recommends that you have the following parts on hand:
•
Cable labels
•
UPS for AC installations
•
ESD wrist or heel straps
•
ESD-safe location
Acme Packet 4600 Shipping Contents
Item
Acme Packet 4600 chassis
Console adapter
AC or DC power cords, one per power supply
Grounding cable with lug
Slide Rail Mounting Kit
4-1
