Specification
Max AC switching current
Max DC switching current

Environmental Specifications

For the Acme Packet 4600 to function properly, Acme Packet recommends that you
follow the environmental guidelines in the following table.
Specification
Temperature
Relative Humidity
Maximum Altitude
Air Flow
Power Dissipation

Connector Specifications

Refer to the following table for information about the connector specifications for the
Acme Packet 4600.
Specification
AC Connector Port
RJ45/Management Ethernet Ports
RJ45/Alarm Contact Port
RS232/Serial Port
1 GbE/10GbE Port(s)
Terminal Block Connections
Environmental Specifications
Value
0.3 A @ 125 VAC
1 A @ 30 VDC
Description
The Acme Packet 4600 is required to operate
within the temperature range of:
0° C to +40° C, 32° F to 104° F (operating)
-20° C to +65° C, -4° F to 149° F (storage)
Operating conditions of 10% to 85% humidity
under non-condensing operating conditions
The Acme Packet 4600 is required to operate
below the maximum altitude of 10,000 feet.
50 CFM front to back
250W typical 350W maximum (base system
with 2 x 10GbE NIU)
Description
The IEC lead connector port on each power
supply accepts a 3-lead IEC-60320 C14
connector for AC power installations (2).
The 3 x 8-pin RJ45 10/100/1000BaseT ports
are compliant with IEEE's 802.3, 802.3u, and
802.3ab.
Any alarms generated by the system are
accessible via the 8-pin RJ45 alarm contact
port.
The RS232 serial port uses an 8-pin RJ45
connector that supports RS232 protocol.
The four 1 GbE fiber optic connection ports
(P0-P3) and the two 10GbE fiber optic
connection ports (P4-P5) use duplex LC
connectors (2).
The terminal block connections accept a bare
(tinned) wire for DC power installations on
each DC power supply (2).
