Oracle Acme Packet 4600 Hardware Installation And Maintenance Manual page 97

Alarm Name Alarm ID
LINK DOWN 131082
ALARM
GIGPORT
LINK UP 131083
ALARM
GIGPORT
LINK DOWN 131084
ALARM
GIGPORT
Management Ethernet Link Alarms
The following table lists the NIU management Ethernet port alarms.
Alarm Name Alarm ID
LINK UP 131077
ALARM
VXINTF
LINK UP 131078
ALARM
VXINTF
LINK UP 131079
ALARM
VXINTF
LINK DOWN 131080
ALARM
VXINTF
LINK DOWN 131081
ALARM
VXINTF
LINK DOWN 131082
ALARM
VXINTF
SFP Presence Alarms
The following table lists the alarms that reflect when an SFP module is inserted or
removed from an NIU.
Alarm Name Alarm ID
SFP 65568
REMOVED
GIGPORT 0
Alarm Cause(s)
Severity
MINOR 10GbE S0P4
link down
MINOR 10GbE S0P5
link up
MAJOR 10GbE S0P5
link down
Alarm Cause(s)
Severity
MINOR Mgmt0 link up Port 0 UP
MINOR Mgmt1 link up Port 1 UP
MINOR Mgmt2 link up Port 2 UP
MAJOR Mgmt0 link
down
MAJOR Mgmt1 link
down
MAJOR Mgmt2 link
down
Alarm Cause(s)
Severity
CRITICAL S0P0 SFP
Removed
Chapter 6
Alarms
Example Log Graphic
Message Display
Message
Slot 0 port 4 X LINK
DOWN ALARMS
Slot 0 port 5 X LINK
UP ALARMS
Slot 0 port 5 X LINK
DOWN ALARMS
Example Log Graphic
Message Display
Message
X LINK
ALARMS
X LINK
ALARMS
X LINK
ALARMS
Port 0 DOWN X LINK
ALARMS
Port 1 DOWN X LINK
ALARMS
Port 2 DOWN X LINK
ALARMS
Example Log Graphic
Message Display
Message
Slot 0 Port 0 X HW
SFP Removed ALARMS:
(where X is
the number of
hardware
alarms
6-38
