Holding the extended bale clasp latch, pull the optical transceiver
3.
fully out of its socket of the physical interface card.

Install an Optical Transceiver

To install an optical transceiver:
Slide the replacement optical transceiver into the socket on the NIU.
1.
Press on the face of the optical transceiver to seat it in the socket.
2.
Flip the bale clasp latch back into the rest position.
3.
Reconnect the optical cables to their corresponding ports.
4.
Optical Transceiver Removal and Replacement
Chapter 6
6-32
