Operator's Manual
Power On
6.6.1. Plug the electrical cord into an appropriate power source.
6.6.2. To turn on the FLEX, flip the power switch that is located on the side of the instrument. The red light indicates
that it is on.
USB Port
Ethernet Port
The FLEX will take about three minutes to
power on and run a self-test. The self-test
will conclude, and the following screen will
be displayed.
If the pressure sensors do not pass, press
"OK" and proceed to the following section
to
adjust
the
Nitrogen
regulators.
If any other component does not pass the
self-test, contact ANKOM.
pg. 14
Electrical Cord
pressure
Power Switch
Rev 1/22/2021
