Ankom Flex Analyte Extractor Operator's Manual page 11

6.5.2. Connect nitrogen supply (N
Pressure (>50psi) Nitrogen source and then attach to the instrument by pushing the black nitrogen supply tubing
into the Nitrogen Supply port on the back of the instrument. Refer to FLEX Service Procedure FLS002.
Nitrogen
Supply Port
6.5.3. Press the reservoir door to open the door. Install the solution reservoir bottles into the correct numbered
positions. Match the colors and numbers of the reservoir bottles to each reservoir cap and tube.
4
3
Rev 1/22/2021
High Pressure) - Attach the black nitrogen supply tubing (part # 8216) to a High
2
Operator's Manual
1
2
pg. 13
