Fast Ethernet Switching System User's Guide
The LED panel is designed to enable you to manage the DES-5200 at a glance.
The LEDs on each module are dealt with in detail.
The LEDs indicate the following:
All LEDs are described in detail. Use the tables to determine the meaning of each
LED. All LEDs are located on the front of the DES-5200, displayed in Figure 12.
Figure 12: DES-5200 LEDs
LEDs
Power
Status
Diagnostic
Utilization
TxRx
Link
100/10
Link/ TxRx
Duplex
Collision
Receiving
Transmitting
Act
4
LEDs
26
