Fast Ethernet Switching System User's Guide
Follow these steps to select a menu:
1.
2.
Follow these steps to select a menu:
1.
2.

System Information

The System Information menu displays the Hardware Revision, MAC address,
LAN IP address and other information on the DES-5200.

System Reset

The System Reset panel enables you to reset the DES-5200 through software
rather than powering off.

Factory Reset to Default Config Values

Enables you to reload factory default configurations.

Switch Control

The advantages and disadvantages of each are explained in a later section.

Software Update

Software can be updated in two ways: XMODEM and TFTP. XMODEM requires
a physical connection between the DES-5200 and a workstation. TFTP can be
done remotely. When updating software over the web, TFTP is the only option
that can be used. Refer to Chapter 5, Software Update for information on updating
software through XMODEM.

Ping

Ping enables user to ping devices and check to see if they are on the network.
Web Management
Click on the folder icon to select it.
Click on the menu to select it.
Use the tab key o the up and down arrwo keys to select an option.
Press Enter.
101
