Fast Ethernet Switching System User's Guide
Monitored Data
Selecting Transmitted monitors all outgoing packet type. Received enables you to
choose either all packet types or one to the three packet types. Transmitted &
Received defaults the monitoring to all packet types.
Monitored Type
This option is only used when the monitored data is set to Received.
Select on of the following types:
Follow these steps to configure port monitoring:
1.
2.
3.
4.
5.
Web Management
All monitors all packet types.
Unicast monitors only unicast packets.
Discard monitors all packets discarded by the DES-5200.
Toggle the space bar to Enable Port Monitoring.
Enter the number of the Monitoring Port.
Enter the number of the Monitored Port.
Toggle the space bar to select the monitored data.
Toggle the space bar to select the packet type to be monitored.
136
