Desktop/ Shelf Installation

The dimensions of the DES-5200 are 17.36 inches (441 mm) x 10.39 inches (264
mm) x 4.64 inches (118 mm). These measurements include the 8 mm rubber feet
provided with the DES-5200.
Follow these steps to install the DES-5200 on a desktop or shelf:
1.
2.
Figure 5: Install Feet on Bottom
Installing the DES-5200
Place the four rubber feet at the corners of the DES-5200. See
Figure 5.
Place the DES-5200 on a desktop/ shelf. See Figure 6.
