Fast Ethernet Switching System User's Guide
Store and Forward requires more memory because the DES-5200 must store the
packet before sending it out.
Address Aging
Address aging is the length of time the address will remain in the MAC address
table.
Follow these steps to change the address aging:
1.
2.

Software Update Menu

The Software Update menu is used to update the software on the DES-5200.
Software can be updated using either XMODEM or TFTP.
XMODEM requires a direct physical connection between a PC and the DES-5200.
TFTP requires a TFTP server and that you know the Internet Protocol (IP) address
of the server and the complete path and filename. TFTP can be done over the
network or from a remote location.
Software Update Configuration
XMODEM
There are two options on the menu displayed in Figure 27. XMODEM is the
default option.
Download Mode
Enables you to select the method for downloading firmware.

TFTP Server IP Address

Enter the address of the TFTP server the firmware is going to be downloaded
from.
File Name
The name of the file to be downloaded.
Managing the DES-5200
Highlight the address aging and enter a new value from 10 to
1000000.
Select Save and press Enter. Select Exit and press Enter to exit the
menu.
52
