Fast Ethernet Switching System User's Guide

1-Port 1000BASE-SX Module

Ac t
1 00 0 B AS E -S X S witched por ts modul e
Figure 18: 1-port 1000BASE-SX Module
The gigabit module, displayed in Figure 18, has one port. Refer to Table 11:
Gigabit Module LED.
Link
The Link LED lights to indicate there is a link at the port.
Act
Act means activity. The Activity LED indicates the port is transmitting or
receiving data.
Table 11: Gigabit Module LED
LED
Link
(Green)
Act
(Flashing Geen)
LEDs
Link
Lit
Port is linked to another
device
Port is transmitting or
receiving data
Dark
No link
Port is not transmitting or
receiving data
