Fast Ethernet Switching System User's Guide
Panel Conventions
Keystroke Conventions
Example
UP, DOWN, or TAB keys
SPACEBAR
DEL, or BACKSPACE
LEFT or RIGHT keys
Ctrl-r
Typographic Conventions
Example
:168.8.254.20
[168.8.254.1]
EXIT
Blinking Text
After you are finished viewing the help panel, press Enter to return to the main
menu.
Managing the DES-5200
Description
Select different items
Toggle-switch
Remove an input character from the screen.
Move cursor backward or forward.
Refresh Screen
Description
Each read only value can be changed only by the
toggle switch.
Each changeable value is enclosed in square
brackets.
Uppercase letters indicate a COMMAND item.
Warning Message.
42
