CEM-C10
To validate the data, long press the
of the Efficiency factors display.
Short press to access the display menu output screen:
4�7�7� Backlight
Long press to view the different options:
Short press the button to browse the different options.
To validate the data, long press the
indicating that the programming value has been saved.
After a few seconds viewing the screen shown in
of the Backlight.
Short press the .button to access the next programming step.
Instruction Manual
The possible options are:
Yes, if you want a display view of the efficiency screens (cost of energy
and CO emissions).
2
No, if you select this option, the unit stops recording the efficiency fac-
tors. A display view is not provided and the value displayed by commu-
nications is 0.
Short press the button to browse the different options.
button. The unit will return to the main programming screen
When this screen is displayed:
Short press the
of the display ( "
4.7.6.1. Partial energy display"
Long press the button to jump to the next programming point.
This is the home screen for selecting the backlight operating mode of
the screen in those units that feature it.
This screen shows the different options:
: Backlight always ON.
On
Off : Backlight always OFF.
005 SEC ... 120 SEC: ON time after the last press of the buttons.
button and the validation screen will appear (
Figure 11
button to return to the first configuration point
, it returns to the main programming screen
)
Figure 11
)
23
