CEM-C10
4�7�5� Type of communications
Note: This is only displayed if there is a
of units) connected to the unit.
Long press the key to view the value to be programmed.
Short press the key to browse the different options.
To validate the data, long press the
that the programming value has been saved.
After a few seconds viewing the screen shown on
type programming main screen.
Short press the key to access the next programming step.
4�7�6� Display
Long press to access the partial energy display selection screen:
4�7�6�1� Partial energy display
Instruction Manual
CEM M-RS485
This is the home screen for selecting the number of bits, the parity
and the number of stop bits of the communications frame.
This screen shows the different options:
: 8 bits, no parity, 1 stop bit.
8n1
8E1 : 8 bits, even parity, 1 stop bit.
8o1 : 8 bits, odd parity, 1 stop bit.
8n2 : 8 bits, no parity, 2 stop bits.
8E2 : 8 bits, even parity, 2 stop bits.
8o2 : 8 bits, odd parity, 2 stop bits.
key and the validation screen will appear (
Figure 11
This is the home screen for selecting the unit display options.
This is the home screen for selecting the partial energy display view
option.
(communications interface for the CEM family
, the system returns to the Communications
) indicating
Figure 11
21
