3�5�- CONNECTIONS
The CEM-C10 has terminal covers to cover the top of the terminal box and the fixing screws (
The fixing screws are of the mixed type, allowing the use of PZ2 and flat head screwdrivers.
Once connected, the unit can be protected with two connection seals (
10
Figure 3: Terminal covers of the CEM-C10�
Measurement terminals ( 1, 3, 4, 6)
Maximum cable cross-section
Screwdrivers head
Impulse output terminals ( 21, 22 )
Maximum cable cross-section
Screwdrivers head
Table 3: CEM-C10 connections�
Connections
25 mm
( 16 mm
2
flat head (1.2 x 6.0 mm) or PH2
1.5 mm
( 1.5 mm
2
flat head (3 x 0.5 mm)
Figure 4: Seal of the CEM-C10�
with end sleeve) ≤ 1.7 Nm
2
with end sleeve ) ≤ 0.6 Nm
2
).
Figure 4
Instruction Manual
CEM-C10
).
Figure 3
