Part Number

Description

649C1082H01

Main Pentium processor circuit board (Quantum 4)

649C1079H01

Main Pentium processor circuit board (Quantum 3)

640D0061H01

Main 486 processor circuit board (Quantum 1 & 2)

640D0062H01

Input/output circuit board #1

640C0024G02

Input/output circuit board #2

640D0063H01

Analog circuit board #1

640C0026G02

Analog circuit board #2

640C0021G01

10.4"diag. LCD color VGA display assembly with backlight

CCFT inverter and mounting plate. (See guide below)

640C0022G01

DC power supply (Condor)

640C0022G11

DC power supply (Power-One)

333Q0000116

Input Module 120 volt AC

111Q0281061

Output Module 120/240 volt AC

640D0060H01

Keypad/overlay Frick's

640D0066H01

Keypad/overlay Gram's

333Q0001193

BR2330 battery (two required)

640B0045H01

Display cable (See guide below)

640B0031H01

Keypad cable

640B0032H01

Back light (CCFT) inverter cable (See guide below)

640B0038H01

DC power harness

333Q0001197

10 Amp circuit breaker

333Q0001198

16 Amp circuit breaker

333Q0000206

Relay, 3 Pole

333Q0000207

Relay base, 3 Pole

333Q0001191

Hour meter

333Q0001192

2.5V CT. Transformer for motor current step-down.

333Q0001194

On/off power switch

333Q0001195

On/off power switch contact block

111Q0280958

Surge suppresser

333Q9991418

Filter, Line

333Q0001326

Fuse, 5 amp, 250 V (I/O board)

333Q0001327

Fuse, .25 amp, 250 V (main board)

Notes:

Note 1 – These processor boards are listed for reference. Each Quantum Control will have only one of these

boards. Order only the replacement board that is applicable to your controller, not both boards.

Spare-1 - Normal spare parts kept on hand. Operation can wait more than 24 hours to receive replacement parts.

Plant typically has back-up compressors.

Spare-2 - Additional spare parts kept on hand. Operation must have parts in less than 24 hours. Plant does not

have back-up compressors.

Spare-3 - Critical operation. Plant must have continuous operation.

FRICK QUANTUM COMPRESSOR CONTROL PANEL

MAINTENANCE
