Setpoint Data Sheets; Factory Setup - Frick QUANTUM Maintenance Manual

S90-010 M
Page 24
In most cases, updating software on the Quantum panel will require clearing the current setpoints and data stored in the
nonvolatile memory on the main board. It is suggested that the operator first record all control setpoints prior to performing
program chip upgrades. Panel Setup and Factory Setup settings will be lost when software is updated. The setpoint data
sheets are useful for recording this information.
Compressor model:
RWBII RXB
SC YLC
Oil pump:
Demand No pump
Oil filter:
Yes No
Refrigerant:
R11
R12
R13
R22
R113
R114
K-factor (If User-Defined): ______
Dual discharge control (used for swing machines):
Enabled Disabled
Liquid injection cooling:
Enabled Disabled
Main oil injection control (used for close-coupled, 2-stage packages):
Enabled Disabled
FRICK QUANTUM COMPRESSOR CONTROL PANEL

SETPOINT DATA SHEETS

FACTORY SETUP

RXF RDB, 4-STEP
YORK S7 Other Var VI
Prelube Cycling
R134a
R290 - Propane
R404a
R500
R502
R503
MAINTENANCE
RDB, 3-STEP GSV II
Other Manufacturer
Full time Shaft w/Aux
GST GSB GRAM/Other
Shaft Dual
R717
R1270 - Propylene
R744 - CO
2
R771
User-Defined
