S90-010 M
Page 8

DISPLAY ASSEMBLY COMPONENT REPLACEMENT GUIDE

DESCRIPTION
10.4" TFT Display
Backlight Inverter
Cable - CPU to Display
Cable - CPU to Inverter
Replacement - Backlight
Display Replacement Assy.
DISPLAY ASSEMBLY COMPONENT REPLACEMENT GUIDE
DESCRIPTION
10.4" TFT Display
Backlight Inverter
Cable - CPU to
Display/Inverter
Replacement - Backlight
Display Replacement Assy.
NOTE A: When upgrading from a Quantum 3 with an NEC Display, to the Quantum 4, the display will need
to be upgraded also. Order 640C0021G01 to replace the display.
FRICK QUANTUM COMPRESSOR CONTROL PANEL
MAINTENANCE

Quantum 3

SAMSUNG
333Q0001180
333Q0001582 (OR 333Q0001181)
640B0036H01
640B0032H01
Not Available
640C0021G01

Quantum 4

SAMSUNG
333Q0001180
333Q0001582 (OR 333Q0001181)
649D4824H01
Not Available
640C0021G01
MANUFACTURER
NEC SHARP
(OBSOLETE)
333Q0001494 333Q0001581
333Q0001495 333Q0001582
640B0043H01 640B0045H01
640B0044H01 640B0032H01
333Q0001587 333Q0001588
640C0021G01 640C0021G01
Rev (A) Rev (B)
MANUFACTURER
NEC SHARP
(OBSOLETE)
333Q0001581
333Q0001582
649D4824H01
SEE NOTE
"A"
333Q0001588
640C0021G01
Rev (B)
LG PHILIPS
(CURRENT)
649C1078H01
333Q0001582
640B0065H01
640B0032H01
333Q0001785
640C0052G01
LG PHILIPS
(CURRENT)
649C1078H01
333Q0001582
649D4824H01
333Q0001785
640C0052G01
