DIGITAL I/O BOARD COMMUNICATIONS SETTINGS

In 120 ohm long communications line termination.
J5
out* No termination. (standard setting)
In RS-422/485 transmit pull-up for long communications lines.
J7
out* No pull-up. (standard setting)
In RS-422 transmit pull-up for long communications lines.
J8
out* No pull-up. (standard setting)
In RS-422/485 receive pull-down for long communications lines.
J9
out* No pull-down. (standard setting)
In RS-422 receive pull-down for long communications lines.
J10
out* No pull-down. (standard setting)
* = standard setting

DIGITAL I/O BOARD DIPSWITCH SETTINGS

SW1
Board #1
Board #2
Board #3
Board #4 off
Board #5
Board #6

ANALOG BOARD COMMUNICATIONS SETTINGS

In RS-422/485 receive pull-down for long communications lines.
J33
Out * No pull-down. (standard setting)
In RS-422/485 transmit pull-up for long communications lines.
J34
Out * No pull-up. (standard setting)
In RS-422 receive pull-down for long communications lines.
J35
Out * No pull-down. (standard setting)
In RS-422 transmit pull-up for long communications lines.
J36
Out * No pull-up. (standard setting)
In 120 ohm long communications line termination.
J37
Out * No termination. (standard setting)

ANALOG BOARD DIPSWITCH SETTINGS

SW1
Board #1 On
Board #2 Off
Board #3 On
Board #4 Off
Board #5 On
Board #6 Off
FRICK QUANTUM COMPRESSOR CONTROL PANEL

JUMPER AND DIPSWITCH SETTINGS

DIGITAL BOARD

SW2
on on
off on
on off
off
on on
off on

ANALOG BOARD

SW2
On
On
Off
Off
On
On
MAINTENANCE
SW3
on
on
on
on
off
off
SW3
On
On
On
On
Off
Off
SW4 SW5
on off
on off
on off
on off
on off
on off
SW4 SW5
On Off
On Off
On Off
On Off
On Off
On Off
S90-010 M
Page 19
SW6
on
on
on
on
on
on
