ANALOG BOARD #2

Input Channel #1 - Future Pid #1
out 0-5 volt input
J1 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #2 - Future Pid #2
out 0-5 volt input
J2 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #3 – Manifold Pressure Eng. Drive
out* 0-5 volt input
J3 1-2 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #4 - Entering Process Temperature**
out 0-5 volt input
J4 1-2 4-20 ma. Input
2-3* ICTD input (standard setting)
Input Channel #5 - Temp.\Pressure Monitoring Aux. #1**
out 0-5 volt input
J5 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #6 - Temp.\Pressure Monitoring Aux. #2**
out 0-5 volt input
J6 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #7 - Temp.\Pressure Monitoring Aux. #3**
out 0-5 volt input
J7
1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #8 - Temp.\Pressure Monitoring Aux. #4**
out 0-5 volt input
J8
1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #9 - Temp.\Pressure Monitoring Aux. #5**
out 0-5 volt input
J9 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #10 - Temp.\Pressure Monitoring Aux. #6**
out 0-5 volt input
J10 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #11 - Temp.\Pressure Monitoring Aux. #7**
out 0-5 volt input
J11 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #12 - Temp.\Pressure Monitoring Aux. #8**
out 0-5 volt input
J12 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
Input Channel #13 - Temp.\Pressure Monitoring Aux. #9**
out 0-5 volt input
J13 1-2* 4-20 ma. Input (standard setting)
2-3 ICTD input
FRICK QUANTUM COMPRESSOR CONTROL PANEL
MAINTENANCE
Input Channel #14 - Side Load \ Economizer**
J14 in* All other input types. (0-5 volt, 4-20 ma.,
ICTD)
out Slide valve potentiometer input.
J15 out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
J16 in* All other input types. (0-5 volt, 4-20 ma.,
ICTD)
out Slide valve potentiometer input.
Input Channel #15 – Main Oil Injector
J17 in* All other input types. (0-5 volt, 4-20 ma.,
ICTD)
out Slide valve potentiometer input.
J18 out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
J19 in* All other input types. (0-5 volt, 4-20 ma.,
ICTD)
out Slide valve potentiometer input.
Input Channel #16 - Kw Monitoring**
0-5 amp CT input
0-5 volt input
4-20 ma. input*
ICTD input
Output Channel #1 – Future
J26 1-2 0-20 ma. output.
2-3 4-20 ma. output
J39 1-2 4-20 ma. output
2-3 0-20 ma. output
IC's install U15 & U7 Connect to P10 terminals 1
& 2
Output Channel #2 - Future
J25 1-2 0-20 ma. output.
2-3 4-20 ma. output
J40 1-2 4-20 ma. output
2-3 0-20 ma. output
IC's install U15 & U6 Connect to P10 terminals 3 & 4
Output Channel #3 – Variable Speed Motor Drive
J24 1-2 0-20 ma. output.
2-3* 4-20 ma. output
J41 1-2* 4-20 ma. output
2-3 0-20 ma. output
IC's install U15 & U5 Connect to P10 terminals 5 & 6
Output Channel #4 - Condenser**
J23 1-2 0-20 ma. output.
2-3* 4-20 ma. output (standard setting)
J42 1-2* 4-20 ma. output (standard setting)
2-3 0-20 ma. output
IC's install U15 & U4 Connect to P10 terminals 7 & 8
** If applicable
Note: IC's must also be installed in order to enable the
analog output options. U15 along with at least one IC
(U4, U5, U6, or U7) installed will enable the channel.
S90-010 M
Page 21
J20 J21 J22
out out in
out out out
in out out
(std) (std)
out In out
(std)
