- Page 1 Crestron C2N-FT-TPS4/TPS4-U FlipTop Touchpanel Control Center Operations & Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron C2N-FT-TPS4/TPS4-U Contents FlipTop Touchpanel Control Center: C2N-FT-TPS4/TPS4-U Introduction ...1 Setup...8 Programming Software...17 Uploading and Upgrading ...22 Problem Solving ...28 Software License Agreement...29 Return and Warranty Policies...31 Operations & Installation Guide – DOC. 6398 Features and Functions...1 Specifications ...2 Physical Description...3 Industry Compliance ...7... -
Page 5: Fliptop Touchpanel Control Center: C2N-Ft-Tps4/Tps4-U
The TPS4 touchpanel is a compact Crestron 3.6-inch touchpanel that provides user interface to a Crestron Functional Summary * As an option, a custom-engraved bezel can be designed and obtained by using the Crestron Engraver software. Version 2.4 and Crestron Database 17.4 or later are available from the Crestron website (www.crestron.com). -
Page 6: Specifications
The units support both Cresnet and Ethernet protocols for communication with other devices as well as uploading programs and firmware. An AC power passthrough is provided with the C2N-FT-TPS4 unit only. Both units provide for extensive connectivity through an easy pull-out cable storage mechanism. -
Page 7: Physical Description
Crestron C2N-FT-TPS4/TPS4-U C2N-FT-TPS4/TPS4-U Specifications (continued) 1. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following 2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product NOTE: Crestron software and any files on the website are for Authorized Crestron dealers and Crestron Authorized Independent Programmers (CAIP) only. - Page 8 FlipTop Touchpanel Control Center TPS4 Physical Dimensions – Top View 4 • FlipTop Touchpanel Control Center: C2N-FT-TPS4/TPS4-U Crestron C2N-FT-TPS4/TPS4-U 7.67 in (19.49 cm) 6.00 in (15.24 cm) CONTROL CENTER CONTROL CENTER CONTROL CENTER CONTROL CENTER CONTROL CENTER (16.64 cm) Operations & Installation Guide - DOC. 6398...
- Page 9 Crestron C2N-FT-TPS4/TPS4-U TPS-4 Physical Dimensions - Front View TPS4 Bottom View Operations & Installation Guide – DOC. 6398 FlipTop Touchpanel Control Center 6.28 in (15.96 cm) 7.17 in (18.22 cm) FlipTop Touchpanel Control center: C2N-FT-TPS4/TPS4-U • 5...
- Page 10 FlipTop Touchpanel Control Center TPS4 Physical Dimensions TPS4 Physical Dimensions - Side View 6 • FlipTop Touchpanel Control Center: C2N-FT-TPS4/TPS4-U Crestron C2N-FT-TPS4/TPS4-U Back View 0.09 in (0.23 cm) 4.66 in (11.84 cm) 5.51 in (14.0 cm) 6.05 in (15.37 cm) Operations &...
-
Page 11: Industry Compliance
(2) this device must accept any interference received, including interference that may cause undesired operation. Operations & Installation Guide – DOC. 6398 FlipTop Touchpanel Control Center SIGNALS TX + TX - FlipTop Touchpanel Control center: C2N-FT-TPS4/TPS4-U • 7 SIGNALS RC -... -
Page 12: Setup
Cresnet power usage of the entire chain. If the unit is a home-run from a Crestron system power supply network port, the Cresnet power usage of that unit is the Cresnet power usage of the entire run. The wire gauge and the Cresnet power usage of the run should be used in the following equation to calculate the cable length value on the equation’s left side. -
Page 13: Crestron Toolbox
The Crestron Toolbox (replacement for Crestron Viewport) is a broad-based software package that accomplishes multiple system tasks, primarily using an RS-232 or TCP/IP connection between a PC and one or more Crestron control systems. You can use the Crestron Toolbox to: The Crestron Toolbox allows you to perform these functions using simple graphical views and click and drag methods. - Page 14 10 • FlipTop Touchpanel Control Center: C2N-FT-TPS4/TPS4-U Crestron C2N-FT-TPS4/TPS4-U 1. Ensure that all network devices are connected to the control system. 2. Open Crestron Toolbox and establish communications (refer to page 22). 3. Select the Network Device Tree Device Tree. (Refer to the following figure.) Network Device Tree 4.
-
Page 15: Installation
Installing Engraved Bezel Use the Crestron Engraver software package to obtain a custom-engraved bezel for the TPS4. Install the replacement bezel as follows. A 1/16” Allen (hexhead) wrench is required for this procedure. - Page 16 The TPS4 is designed to mount in a horizontal surface, such as a desk top, lectern, or podium. The following diagram illustrates the required opening size to accommodate the TPS4. A cutout template (4007478) is included. 12 • FlipTop Touchpanel Control Center: C2N-FT-TPS4/TPS4-U Crestron C2N-FT-TPS4/TPS4-U PART DESCRIPTION Small Cable Bushing, 5/16 inch ID, 0.5 inch OD...
- Page 17 3. Install the four #10 screws in the mounting brackets (two screws per bracket). Refer to the following diagram. 4. Slide the mounting brackets over the #6-32 screws and tighten the #6-32 screws. FlipTop Touchpanel Control center: C2N-FT-TPS4/TPS4-U • 13 QUANTITY...
-
Page 18: Hardware Hookup
Contact with thermal insulating materials should be avoided on all sides of the unit. 14 • FlipTop Touchpanel Control Center: C2N-FT-TPS4/TPS4-U Crestron C2N-FT-TPS4/TPS4-U 5. Turn the four #10 screws equally until they contact the underside of the mounting surface. -
Page 19: Configuring The Touchpanel
NOTE: The touch screen responds to both finger and stylus commands. Since the screen is small, Crestron recommends that a stylus (not supplied) be used to ensure the accuracy of commands. Use a stylus that will not damage the surface of the screen. -
Page 20: Setup Menu
DOWN buttons to set the Cresnet network identity (CRESNET ID). Use the other buttons on the screen to enable/disable the preferred communications protocol: Cresnet II, Ethernet, or CIP (Crestron Internet Protocol). Cresnet II buttons determine the touchpanel’s communication mode. Select Enable for normal Cresnet communications (default);... -
Page 21: Programming Software
Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website. To post a question or view questions you have Operations & Installation Guide – DOC. 6398... -
Page 22: Earliest Version Software Requirements For The Pc
Crestron’s True Blue Support, log in at http://support.crestron.com. First-time users will need to establish a user account. You can create a program that allows you to include the TPS4 in a Crestron control system. The program output of Crestron SystemBuilder is a SIMPL Windows program with much of the functionality encapsulated in macros and templates. -
Page 23: Programming With Systembuilder
Crestron SystemBuilder is fully integrated with Crestron's suite of software development tools, including SIMPL Windows, VT Pro-e, Crestron Database, User IR Database, and User Modules Directory. Crestron System Builder accesses these tools behind the scenes, enabling you to easily create robust systems. - Page 24 Ethernet instead of Cresnet. Setting the Net ID in Device Settings Double-click the C2N-FT-TPS4 (Cresnet) icon in the upper pane to open the “Device Settings” window. This window displays TPS4 device information. The Net ID can be changed in this window using the Net ID tab, as shown in the following figure.
-
Page 25: Example Program
If you wish to have the program sense the open and closed position of the flip top, insert the Flip Top Open/Close device extender. Example Program An example program for the C2N-FT-TPS4/TPS4-U is available from the “Example Program” section of the Crestron website (www.crestron.com/exampleprograms Search for C2N-FT-TPS4/TPS4-U.ZIP. -
Page 26: Uploading And Upgrading
PC. The PC may be disconnected from the control system or panel except during reprogramming. When you start the VT Pro-e project for this product, select C2N-FT-TPS4 as the panel type. - Page 27 Operations & Installation Guide – DOC. 6398 FlipTop Touchpanel Control Center 1. Open Crestron Toolbox and click Tools | Manage Address Book to display the communications settings. The DefaultAddressBook.adr file contains several default address settings. Select Serial on COM 1 for serial communication.
-
Page 28: Uploading A Simpl Windows Program
Upload via Crestron Toolbox 24 • FlipTop Touchpanel Control Center: C2N-FT-TPS4/TPS4-U Crestron C2N-FT-TPS4/TPS4-U 2. After setting the correct parameters, click OK to return to the Crestron Toolbox main window. 3. Select Tools | System Info. If the connection is successful, the System Info window displays the processor and device information. - Page 29 6. To verify that the program has been transferred successfully, select Functions | SIMPL Program. Details about the current program loaded in the control system are displayed in the upper left corner of the “SIMPL Program” window. FlipTop Touchpanel Control center: C2N-FT-TPS4/TPS4-U • 25...
-
Page 30: Firmware Upgrade
FlipTop Touchpanel Control Center Firmware Upgrade To take advantage of all the C2N-FT-TPS4/TPS4-U features, it is important that the unit contains the latest firmware available. Please check the Crestron website for the latest version of firmware. Not every product has a firmware upgrade, but as Crestron improves functions, adds new features, and extends the capabilities of its products, firmware upgrades are posted. - Page 31 .zip file. Click Send to transfer the file. The File Transfer window monitors the transfer of the file and gives you the option of canceling the transfer. “File Transfer” Window FlipTop Touchpanel Control center: C2N-FT-TPS4/TPS4-U • 27...
-
Page 32: Problem Solving
For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
