Configuration

6 Configuration
6.1

Basic Configuration

It is possible to add information about the configuration in fields Author, Configuration Name and
Additional Info in the configuration tree entry Info.
It is possible to create and save a configuration without a connected device. Saved configurations can be
downloaded to connected CAN NT devices with Windows and Linux by using the Command Line Tool (see
Downloading the Configuration with Linux, p.
1
Fig. 2 CAN-Gateway Configurator
1
Information about target device, STS (status) reflects Power LED of device
2 Drop-down list Select device type
3
Drop-down list Select device version
4 Drop-down list Select operational mode
5 Button New
6 Button Open
7 Button Save
8 Button Save as
9
Button Verify
10 Button Scan
11 Combo Box Target device
12 Button Connect
13 Button Write to
14 Button Read from
Make sure, that the latest VCI driver is installed.
►
► Make sure, that the device is correctly installed (see
► Connect a device to the host computer via Mini USB cable.
► Make sure, that the latest firmware is on the device (see
Firmware, p.
CANbridge NT User Manual
The security settings set via the CAN-Gateway Configurator define if a password is
needed to change the configuration. The default password is IXXAT. For more information
see user manual CAN-Gateway Configurator.
Connection disturbance possible if extension cable or longer cable is used!
HMS recommends connecting the interface directly with the included cable or via an
active USB hub to the computer according to the USB specification.
2 3 4
11).
17).
5 6 7 8 9 10
Installing the Hardware, p.
Checking and Updating the
13 (26)
11
12 13 14
8).
