Product Description

4 Product Description
To use all features the latest version of the CAN-Gateway Configurator as well as the latest firmware of
the CAN@net NT must be installed. For documentation of firmware versions below V6 contact Ixxat
support.
The CAN@net NT hardware provides connectivity to Ethernet and CAN networks with various
operational modes. The CAN@net NT 420 additionally is capable of CAN FD. The application
firmware provides functions to access a CAN bus from virtually every Ethernet host. The
CAN@net NT provides message filtering, based on CAN identifiers, for Bridge and Gateway mode
in the direction from CAN system to TCP/IP network. In the Gateway mode the filter can be
configured by ASCII commands. In the Bridge mode the configuration tool is used to configure
the filter. With the VCI driver the CAN@net NT can be used as a PC interface.
4.1

Features

• CAN@net NT 100: 1 x CAN connections (D-Sub 9 connector)
• CAN@net NT 200: 2 x CAN connections (terminal adapters)
• CAN@net NT 420: 4 x CAN connections (terminal adapters), via the CAN-Gateway
Configurator two connections can be switched between Classic CAN and CAN FD
• 1 x RJ45 Ethernet port, 10/100 Mbit/s
• 1 x mini USB 2.0 port, high-speed
• CAN/CAN FD according to ISO 11898-1:2015
• CAN high speed according to ISO 11898-2:2016
• configuration via USB or Ethernet
• platform independent due to ASCII protocol
• With the CAN-Gateway Configurator a configuration can be created, modified, written to
and read from the target device via USB or Ethernet connection.
The configuration of the following features are described in detail in the User Manual CAN-
Gateway Configurator CANbridge NT & CAN@net NT 100/200/420:
• Classic CAN/CAN FD ID filtering (mapping)
• Classic CAN to CAN FD mapping and CAN FD to Classic CAN mapping (with NT 420)
• J1939 mapping
• cyclic transmission of CAN messages
• MQTT and syslog functionality
• command line program CANGWfile (available for Windows and Linux)
• action rules via if-this-action-then-that-event functionality
• remote access via ASCII protocol
4.2

Default Configuration

By default the CAN@net NT is configured as VCI interface and can be used as PC interface with
Windows.
