Configuration
6.5

Downloading the Configuration with Linux

The basic configurations, like the selection of the operating mode, can only be created with the
CAN-Gateway Configurator with Windows. A configuration can be created and saved without a
connected device and can then be downloaded to connected CAN NT devices with Linux by using
the Command Line Tool that is included in the scope of delivery.
► To be able to read and write configurations on CAN NT devices, copy the included file 60-bgi.
rules to the folder /etc/udev/rules.d/ (root access required).
► To activate the new rules, execute the following command:
udevadm control - -reload-rules
To download a saved configuration file to CAN NT devices, start the command line tool
►
cangwfile without parameters.
→ Output shows the syntax, examples and all possible commands.
► Write the configuration to the target device (see User Manual CAN-Gateway Configurator
for more information about the Command Line Tool).
6.6

Reset to Factory Settings

It is possible to reset the configuration of a connected device to factory settings.
Fig. 6 Menu Reset to Factory Settings
► Connect the device via USB.
Open menu Target and select Reset to Factory Settings.
►
Click button Yes to confirm the reset.
►
