7.2.3 User LED
Indicates the primary application status and can be configured with user defined settings via
Action Rules. See User Manual CAN-Gateway Configurator for more information.
7.2.4 CAN LED
CAN 1-4 LEDs indicate the status of the corresponding CAN interface.
LED state
Off
Orange flashing
Green flashing
Green
Red flashing
Red
CANbridge NT User Manual
Description
No CAN communication
Indicates a state of the automatic
baud rate detection
CAN communication
CAN communication
CAN communication, CAN
controller in Error state
Bus off
Comments
No connection to CAN
See User Manual CAN Gateway Configurator
LED is triggered with each CAN message
Device in Operational state, no messages on CAN bus
CAN controller in Error Warning or Error Passive state,
reception/transmission of CAN messages possible
CAN controller is in Bus Off state, no CAN
communication possible
