Safety Instructions

2 Safety Instructions
2.1

General Safety Instructions

Protect product from moisture and humidity.
►
► Protect product from too high or too low temperature (see
► Protect product from fire.
► Do not paint the product.
Do not modify or disassemble the product. Service must be carried out by HMS Industrial
►
Networks.
Store products in dry and dust-free place.
►
2.2

Indented Use

The components are used to connect CAN and CAN FD networks with each other. They are
intended for installation on standard DIN rail.
3

Scope of Delivery

Included in scope of delivery:
• CANbridge NT
• 1 x power connector
• 2 x CAN connector (with CANbridge NT 200)
• 4 x CAN connector (with CANbridge NT 420)
• User Manual CANbridge NT
• Installation Guide VCI Driver
• Mini USB cable
The following is available for download on the CANbridge NT support pages on
www.ixxat.com/support-bridges-gateways:
• CAN-Gateway Configurator
• VCI driver
• User Manual CAN-Gateway Configurator for CAN@net NT and CANbridge NT
• User Manual CAN@net NT/CANbridge NT Lua ADK
CANbridge NT User Manual
Risk of interference to radio and television if used in office or home environment!
Use exclusively included accessories. Use exclusively shielded cables.
Make sure that the shield of the interface is connected with the device plug and the plug
on the other side.
Connection disturbance possible if extension cable or longer cable is used!
HMS recommends connecting the interface directly with the included cable or via an
active USB hub to the computer according to the USB specification.
Technical Data, p. 21).
