Installation
► Open menu Target and select Read configuration from target.
► Save the configuration on the computer.
► Open menu Target and select Update Firmware.
► Select the update file.
→ Firmware of the connected device is updated.
In the status window check if the update is completed successfully.
►
► If the device was updated from V5 to V6 , select V6 in drop-down list Select device version.
► If using a V5 configuration, open menu File and select Convert V5 to V6 to convert the
configuration to the latest version.
► Write the saved configuration to the device.
HMS recommends to verify configurations that are converted from V5 to V6, to make sure that all
settings are working correctly.
