6. Configuration

6.1. Prerequisites

For this integration, you will need:
• The items supplied by HMS Networks:
– The Intesis gateway
– The gateway documentation
– The gateway ETS database
• An ETS5 license (version 5.7.7 onwards).
• An operative KNX control system, properly connected to the KNX port of the Intesis gateway.
• The Modbus server device(s) or installation you are about to integrate, connected to the Port A (EIA-485) of
the Intesis gateway.
• A Windows® computer to run the ETS configuration tool.

6.2. Configuration Process with the ETS Tool

This Intesis gateway is officially certified by KNX. Use the standard KNX configuration tool ETS to set up the
gateway. You can find the ETS database for this gateway in the ETS catalog or download it from here.
NOTE
When importing the gateway to the ETS software for the first time, it will show 10 Modbus active
signals, each configured as a Read and Write signal. You can configure these signals later and adapt
them to your project needs.
