LAN Switch Specifications

4.3. LAN Switch Specifications

4.3.1. Boot Process

After powering on or requesting a reboot of the Ewon
before the LAN switch feature is fully operational.
IMPORTANT
®
The Ewon Cosy+ should not be used as a pure Ethernet switch as short interruptions of the switch
interface need to be taken into consideration.
NOTE
®
The Ewon Cosy+ may reboot when it can no longer run a configuration. The goal of the reboot is to
restore the communication channels and to ensure that the configuration is applied.

4.3.2. LAN Switch Configuration

At the very first boot or after a reset level 2, the Ethernet ports scheme will be configured as follows:
• Port #1 : LAN
• Port #2 : LAN
• Port #3 : LAN
• Port #4: WAN
NOTICE
Ethernet port#1 must be used for maintenance operation (such as update).
The Ethernet port's functionality can be configured as wanted except for the port #1 which always remains in
LAN mode.
TIP
You can identified the LAN port by its green LED and the WAN ports by their orange LEDs.

4.4. Radio Communication Models

IMPORTANT
This device is intended to be used in fixed or mobile applications only (not for portable applications).
IMPORTANT
The antenna used for this transmitter has to be installed in a space providing a safe distance of a
least 20 cm without encountering anyone and cannot be located or operating in conjunction with
any other antenna or transmitter.
Technical specifications and certifications by models can be found in the
IG-0031-00 1.2
®
Cosy+, a delay (approximately 2 to 4 sec) is required
®
Ewon Cosy+ models (page 15)
®
Ewon Cosy+
section.
Page 14 of 32
