Mechanical Dimensions

Figure 3-5
shows the board's dimensions in inches.
0.000
0.000
0.250
0.250
0.000
0.000
0.250
0.250
Figure 3-5. Mechanical Dimensions (in Inches)
ADSP-21992 EZ-KIT Lite Evaluation System Manual
EZ-KIT Lite Hardware Reference
7.000
7.000
5.000
5.000
3-27
