Table 3-5. DAC Outputs Connector (P5) (Cont'd)
Pins
3
4
5
6
7
8
9
10

Encoder Interface Connector (P6)

Differential encoder signals can be applied to the ADSP-21992 EZ-KIT
Lite board at the encoder interface connector (P6) as shown in
Table 3-6. Encode Interface Connector (P6)
Pins
1
2
3
4
5
6
7
8
9
10
ADSP-21992 EZ-KIT Lite Evaluation System Manual
EZ-KIT Lite Hardware Reference
Name
DAC1
DAC2
DAC3
DAC4
DAC5
DAC6
DAC7
AGND
Name
DGND
EIZ+
EIZ-
DGND
EIB+
EIB-
DGND
EIA+
EIA-
DGND
Signal
DAC channel 1
DAC channel 2
DAC channel 3
DAC channel 4
DAC channel 5
DAC channel 6
DAC channel 7
Receive clock
Signal
Digital ground
Differential north marker Z+
Differential north marker Z-
Digital ground
Differential quadrature pulse input B+
Differential quadrature pulse input B-
Digital ground
Differential quadrature pulse input A+
Differential quadrature pulse input A-
Digital ground
Table 3-6.
3-21
