Table 3-8. Programmable Flag Interface Connector (P8) (Cont'd)
Pin
8
9
10
11
12
13
14
15
16
17
18
19
20

UART (RS-232) Interface Connector (P9)

A standard female RS-232, D-sub, 9-pin connector is used for the UART
interface circuitry on the ADSP-21992 EZ-KIT Lite board. Refer to
Table 3-9.
Table 3-9. UART (RS-232) Interface Connector (P9)
Pin
1
2
3
4
ADSP-21992 EZ-KIT Lite Evaluation System Manual
Name
PF6
PF7
DGND
PF8
PF9
PF10
PF11
PF12
PF13
PF14
PF15
CONVST
DGND
Name
1-4-6
T1O
R1E
1-4-6
EZ-KIT Lite Hardware Reference
Signal
Programmable flag 6
Programmable flag 7
Digital ground
Programmable flag 8
Programmable flag 9
Programmable flag 10
Programmable flag 11
Programmable flag 12
Programmable flag 13
Programmable flag 14
Programmable flag 15
ADC external convert start
Digital ground
Signal
Transmit
Receive
3-23
