Power Supply Connector (P1); Serial Port Connector (P2); External Memory Interface (Emi) Connector (P3) - Analog Devices ADSP-21992 EZ-KIT LITE System Manual

Power Supply Connector (P1)

Refer to "Power Supplies" on page 3-2
ply connector (P1).

Serial Port Connector (P2)

The SPORT is connected to a 10-pin connector as shown in
Table 3-3. SPORT Connector (P2)
Pins
1
2
3
4
5
6
7
8
9
10

External Memory Interface (EMI) Connector (P3)

Refer to the schematics in Appendix A, at the end of this document for the
pinout of the EMI connector.
ADSP-21992 EZ-KIT Lite Evaluation System Manual
EZ-KIT Lite Hardware Reference
Name
+3.3V
DR
DGND
DT
NC
+3.3V
TCLK0
TFS
RFS
RCLK
for details of the input power sup-
Signal
Vddext
Receive data
Digital ground
Transmit data
No connection
Vddext
Transmit clock
Transmit frame sync
Receive frame sync
Receive clock
Table 3-3.
3-19
