Table 3-10. PWM, AUXPWM, TMR Interface Connector (P10) (Cont'd)
Pin
14
15
16

USB Connector (P11)

The USB connector is a standard type B USB receptacle.
Table 3-11. USB Connector (P11)
Part Description
Type B
USB receptacle
Mating Connector
USB cable
(provided with EZ-KIT Lite

CAN Interface Connectors (P12, P13)

There are two connectors associated with the CAN interface circuitry on
the ADSP-21992 EZ-KIT Lite board. Connectors P12 and P13 provide
connections to the user's CAN bus and allow easy daisy-chaining of CAN
devices.
Table 3-12. CAN Interface Connectors (P12, P13)
Pin
1
2
ADSP-21992 EZ-KIT Lite Evaluation System Manual
Name
TMR0
TMR1
TMR2
Manufacturer
Mill-Max
Digi-Key
Assmann
Digi-Key
Name
DGND
CANL
EZ-KIT Lite Hardware Reference
Signal
General-purpose timer I/O
General-purpose timer I/O
General-purpose timer I/O
Part Number
897-30-004-90-000
ED90003-ND
AK672-5
AK672-5ND
Signal
Digital ground
CAN receive
3-25
