88 Hydraulic System Maintenance
7.
When the inspection is completed, put back the safety prop and lower the body.
Replacing the Body Hoist
DANGER!
Never prop a loaded body. Unload the body prior to doing any repairs.
To replace the body hoist:
1.
Lock out and tag out the vehicle (see Lockout/Tagout Procedure on page 22).
2.
Disconnect the hydraulic hose and fitting.
Figure 7-19
Hydraulic fitting
3.
Remove the 2 cylinder base pillow blocks (see Figure 7-20) by unscrewing the bolts that hold
them in place.
Figure 7-20
Base pillow blocks
