Figure 7-2
3-section valve with corresponding functions
Figure 7-3
5-section valve with corresponding functions
F
D
C
B
A
E
D
C
B
A: Pressure/Return
B: Hoisting cylinder
C: Bucket
D: Tailgate
A
A: Pressure/Return
B: Hoisting cylinder
C: Right-side bucket
D: Tailgate
E: Left-side bucket
F: Maximizer
Hydraulic System Maintenance 75
