If the gap between the gland and the tube is wider than 1⁄8 inch, you must call LabriePlus
immediately. Should the gap between the tube and the gland be wider than 1 inch, you must stop
using the vehicle immediately and replace the cylinder (see Replacing the Body Hoist on page 88).
DANGER!
It is mandatory to inspect cylinder gland weekly. If the cylinder gland is unscrewed from
the body hoist, it will cause separation of the hydraulic cylinder, and the body will
suddenly drop.
This type of accident can lead to damage, serious injury, and even death.
Figure 7-17
Gap
6.
Make sure that the gland safety pins are in place.
Figure 7-18
Safety pin
N
: Not all hoist cylinders have this type of safety pin.
OTE
Less than
1/8˝ gap
Hydraulic System Maintenance 87
