4.
Take a 4-foot, 2 in. x 4 in. wood beam (see Figure 5-4) and set one end in the rail, at least 4 inches
below the rollers.
5.
Apply a lever force against the loading bucket to push it towards the body.
This will reduce pressure from the rollers against the access cover.
WARNING!
Be very careful while performing this step. Failure to do so could result in death or in
serious injury.
Figure 5-4
Using a wood beam
6.
Have a helper open up the access cover while you maintain the bucket pushed inwards.
7.
Slowly step back with the beam to let the rollers swing out of the rail.
Figure 5-5
Bucket rollers and rail
8.
Repeat Steps 3 to 6 for the two rollers located at the other end of the loading bucket.
9.
Clean the rails with pressurized steam or any grease cleaning device.
10.
When the maintenance is completed, use the beam to push the bucket back in the rail and have a
helper put the covers back in place.
Loading Container Maintenance 45
