NOTES:
• In order to ensure that the cable lock is not unintentionally unlocked,
keep the area within 2 inches of all cable locks in any direction free of any
other objects.
• The total cable length includes 1 inch of cable that must extend beyond
the cable lock, as shown in the following illustration.
• If cable locks need to be within 2 inches of each other they must be at
the same height.
Steel Cable
E
T
E
≥2"
≥2"
F
F
PendantConnect-2
Cable
Figure 22. Bulk Pendant Connect-2 Cable Cut Length
2. Determine and mark the strip points, (see
3. Cut the cables using value T as the cut length.
Pipe
Cable Lock
C
Pipe
≥2"
≥1"
≥2"
E
F
≥1"
A
B
Floor
figure 21, E and F).
SF 28PT User Guide • Reference Information
Cable locks
must be at the
same height
as each other.
Steel Cable
C
Cable
≥2"
Lock
≥1"
2" min.
Strip Point E = A - B - 13.12
Strip Point F = 10"
Total Length T = A - B - G + C
G = 7.37"
T= Total length of PendantConnect-2 cable
