Installing Vertical Cable Guides (VCGs)
Install the VCGs (one per side) as shown in
VCG (2)
1U FIBER PANEL
VCG (2)
2U FIBER PANEL
Figure
INSTALLATION
HOLES FOR VCG
Figure 5. Installing Vertical Cable Guides
ADCP-92-082 • Issue 2 • 10/2008
5.
INSTALLATION
HOLES FOR VCG
© 2008, ADC Telecommunications, Inc.
6-32 SCREWS
(2 PER VCG)
(PROVIDED)
22051-A
6-32 SCREWS
(2 PER VCG)
(PROVIDED)
Page 7
