ADCP-92-082 • Issue 2 • 10/2008
Figure 16 shows routing from the left side.
IF NECESSARY, PULL EACH 900 MICRON FIBER FROM
STUB END OF SUBUNIT, TO CORRECT LENGTH TO
ELIMINATE SLACK AT ADAPTER PACK.
4.1.2

Routing OSP Cable, Right Side Entry

For right side cable entry, route the OSP cable from the cable clamp position to the splice tray as
shown in Figure
panel.
Page 16
© 2008, ADC Telecommunications, Inc.
SLACK LOOP AROUND OUTSIDE OF
NOTE:
SPLICE TRAY IS NOT REQUIRED
RECOMMENDED CABLE
LENGTH FROM STUB END
TO CONNECTOR IS 108 INCHES
STUB
FOR SPLICE TRAY ROUTING,
END
"SPLICE TRAY ROUTING"
Figure 16. Routing Pigtails from Left Side (Top View)
17. Note that "right" is defined here from the perspective of the front of the
SEE SECTION 3.3,
CORRECT LENGTH AT ADAPTER PACK
22061-A
