10.10 High Voltage Board (PR31001C)
Circuit No. Part No.
Q1 503203071 Transistor
D1, 2 503100181 Diode
D4 503100172 Diode
D3, 5 503100173 Diode
L1 510033250 Transformer
R1 501303810 Resistor
R2, 3 501303797 Resistor
R5, 6 501303811 Resistor
R4 501303805 Resistor
C1 502102224 Capacitor, Electrolytic
C2 502102225 Capacitor, Electrolytic
C3 502403105 Capacitor
C4, C5 502103101 Capacitor, Ceramic
773503490 High Voltage Board
FC2230-UM-251-01-1600
Description Rating
2SC2719L
SD, TFR2T
SD, RD4.7E-B3
SD, 1S1585
HVT, 31001C
R20T-24J104
R20T-24J102
R20T-24J514
R20T-24J103
CE, 35UTCMDT220
CE, 16UTCMDT100
CC, RPU05B222K
DE, 1010B471K6KV
PR31001C Assembly
Q'ty
1
2
1
2
1
1
2
2
1
1
1
1
2
1
1 0-13
