10.7 Pen Flex Board (PR223226A)

Circuit No.
Part No.
PCB
682807261 PCB
J61
513101160 Connector
P62
513100926 Connector
122927343 Cable
FC2230-UM-251-01-1600
Description
PR223226A
CN, 52044-1010
CN, IL-G-10PS3L2E
CA2292-34C
Rating
Q'ty
  1 0-10
1
1
1
1
