10.6 X-Y Joint Board (PR223225A)

Circuit No. Part No. Description
PCB 682807251 PCB
U1 504084558 IC
D1,2,3,4 500000731 Diode
C1,2 500000645 Capacitor, ceramic
J52 513101160 Connector
J51 513101159 Connector
P501 502312170 Connector
P503 502312171 Connector
P502 505100040 Connector
FC2230-UM251-01-1600
Rating Q'ty
PR223225A 1
NJM4558D 1
SD, AL01Z 4
CC, RPU08F103Z-T 2
CN, 52044-1010 1
CN, 52044-2310 1
IL-G-2P-S3T2-E 1
IL-G-3P-S3T2-E 1
IL-G-4P-S3T2-E 1
10-9
