GRAPHTEC Cutting PRO FC2230 Series Service Manual page 127

9.6 X Drive Unit
No. Part No.
50 022900013
022900103
51 022903511
022903772
52 022903631 Belt Plate B
53 022903691 Roller Collar B
54 022904212 Spacerφ04-1.5
55 022903612 Sensor Dog
56 362200005 Rubber Foot
E1 772230250 X Limit Switch
E2 509000004 X Motor
E3 162291230
162291240
60 022904540 XR End
61 022904560 XR Pulley Bracket
62 022904530 XF End
63 022904550 XF Pulley Bracket
64 622301630 Belt Plate
FC2230-UM251-01-1600
Description
Writing Panel 12
Writing Panel
X Rail, Rear 12
X Rail, Rear
X Flexible Cable
X Flexible Cable
Q'ty Remarks
1 FC2200-90
FC2200-90/EX
1 FC2200-90
FC2200-90/EX
2
2
2
1
1 SJ5008
1 PR223208
1 UGFMEDA5LGR27
1 FC2200-90
FC2200-90/EX
1
1
1
1
2
(2/2)
9-12
